PREPARATION
PS-3
C
D
E
F
H
I
J
K
L
M
A
B
PS
PREPARATION PFP:00002
Special Service Tools
BGS0001Q
Description Application
Preload gauge
ST3127S000
● Checking steering torque
● Pinion gear rotating torque measurement
for steering gear
ST27180001
Steering wheel puller
Removing steering wheel
ZZA0806D
S-NT544
