Introduction

Thank you for choosing the M-Audio Audiophile 192 PCI interface, your professional solution for audio and MIDI performance with your computer

and Digital Audio Workstation software. The Audiophile 192 provides your computer with a high-resolution four-input, four-output audio interface,

as well as sixteen channels of MIDI in and out. The Audiophile 192 is the latest in M-Audio’s acclaimed Delta series of digital recording interfaces,

based on a proven solid hardware design and innovative software driver technology.

Even if you are an experienced computer user and digital recording enthusiast, we suggest you take the time to read this brief user’s manual. It

will help to streamline the installation procedure, and acquaint you with the Audiophile 192’s superior feature set, allowing you to quickly realize

the full potential of this powerful audio tool.

Overview

The Audiophile 192 is a professional quality audio and MIDI interface based on a low-proﬁle PCI card, offering two analog inputs and four analog

outputs (balanced or unbalanced TRS) on a robust breakout cable. The Audiophile 192 also offers independent S/PDIF coaxial I/O.

The Audiophile 192 supports a wide range of internal sampling rates, from 8kHz up to 192kHz, for clean, high-resolution 24-bit audio performance.

It can also sync to external devices via S/PDIF at sampling rates from 32kHz to 192kHz. The Audiophile 192 runs under Windows XP, Windows

2000, and Mac OS X, and includes ultra-low latency drivers for the most popular audio protocols, including Windows WDM, ASIO II, GSIF II

(backward-compatible) and Mac CoreAudio.

The Audiophile 192 also offers a highly ﬂexible software mixer, giving you zero-latency input monitoring. As part of the Delta series of M-Audio

interfaces, the Audiophile 192 can be used together with other Delta series devices (or with multiple Audiophile 192’s), and can be synchronized

via the control panel’s multiple card sync page in Windows XP (multiple card support is planned for Mac OS X in a future software update). MIDI

I/O is also included, making the Audiophile 192 a total studio solution.

Features

< Frequency response 20Hz – 80kHz

< 24-bit, 192kHz audio interface with an exceptional 113dB dynamic range

< Supports internal sample rates of 8kHz to 192kHz, and will sync via S/PDIF to external sample rates of 32kHz to 192kHz

< Supports Windows XP (SP1), Windows2000 (SP2) and Mac OS X (10.2.8, 10.3.4 and higher)

< Extremely low latency ASIO II and WDM drivers, as well as GSIF II and Mac CoreAudio drivers

< Two balanced/unbalanced analog inputs on 1/4” TRS connectors

< Two balanced/unbalanced analog Main outputs on 1/4” TRS connectors

< Two balanced/unbalanced analog Monitor outputs on 1/4” TRS connectors

< Stereo S/PDIF inputs and outputs on RCA coaxial connectors

< MIDI I/O

< Software-controllable analog mixer provides monitoring of input signals to Monitor outputs

< User-friendly Control Panel offers control of mixing, routing, and master clock settings

< Support for VST System Link and WMA Pro

What’s in the Box

< One Audiophile 192 PCI Card

< One Audiophile 192 breakout cable for analog audio and MIDI connections

< M-Audio Driver CD with PDF manual

< M-Audio Warranty Registration Card

< Adobe Acrobat Reader

Minimum System Requirements

Windows

< Pentium 3 – 700 MHz or higher, 256 MB RAM (192 and 96kHz operation)

< Pentium 3 – 500 MHz or higher, 128 MB RAM (48kHz operation)

< DirectX 9.0b or higher

< Windows XP (SP1) or Windows 2000 (SP4)

< Available PCI slot
