Install the joint horizontally so that the attached warning label

faces strait up, and the tilt is within ±15°.

(Refer to figure 18-1)

Do not install vertically. (Refer to figure 18-2)

• Maintain a straight portion of 500 mm or more until the split of

the joint without wrapping any onsite piping around this area.

Over 500 mm of straight area can be maintained by connect-

ing at least 120 mm of onsite pipe (straight) to the joint.

(Refer to figure 18-3)

(Refer to figure 18)

1. Warning label

2. Horizontal surface

3. ±15° or less

4. Ground

5. Onsite pipe (120mm length or more)

6. Straight part of 500mm or more
