121

3. Slide – used to adjust the suction by uncovering or covering the hole under the slide.

ATTENTION!!! While collecting liquids, wet or steam cleaning the slide should cover the hole

completely.

Extension tubes (detergent/steam) connect the hose (detergent/steam)

with a proper nozzle through (or without) a connector. Depending on the

particular application and the height of the user one or two extension tubes

can be used.

Connector – is used to connect the tube (detergent/steam) only with

a big or small spray nozzle.

Big spray nozzle – shall be used to

collect water or for wet cleaning.

Cleaning insert – is installed in the big spray nozzle.It is used to

collect water from hard backgrounds, e.g.parquet ﬂ oors, linoleum,

ceramic tiles, etc.and to perform wet cleaning.

Small spray nozzle – shall be used wet cleaning the upholstery, e.g.on chairs,

armchairs, beds, car seats, etc.

Preparation of the vacuum cleaner to wet cleaning

Prior to wet cleaning thoroughly vacuum the area and prepare the vacuum cleaner.To do this:

Switch the vacuum cleaner off by pressing the main switch and remove the plug –

from the socket.

Turn the hose until the ▼ symbols on the hose and the container are located –

opposite to each other.Remove the hose from the slot.

Open the upper cover and remove the front container. –

Take the water ﬁ lter out of the container. –

Remove the dust collected in the ﬁ ltration chamber or remove a paper bag. –

Remove the dirty water from the container and rinse the container. –

Insert the water ﬁ lter to the container without a paper bag and a ﬁ ltering insert. –

Place the container on the base and close the upper cover. –

Then, follow the instructions given in the p.“Collecting liquids” –

on how to install the hose, extension tubes, connector, spray

nozzles and the stub.

Then:

Uninstall the rear container: –

open the upper cover and set it vertically ( – 1),

lift the container and then move it backwards ( – 2).

Remove the inlet cap and pour a cleaning agent (powder or ﬂ uid) into the container. –

The amount of the agent is given on the label:

Powder – preparation of the cleaning solution: in a separate –

container dissolve the contents of the bag in 2.5 – 3l of water

(temp.of up to 45°C).

Fluid: pour a measured amount of the ﬂ uid into the rear –

container.1 bottle cap of the liquid per 3.5l of water.

Depending on the cleaning agent chosen, ﬁ ll up the rear container with the –

solution or warm water (up to 45°C).

Put the inlet cap in place. –

ATTENTION!!! The vacuum cleaner is equipped with only one type of the cleaning agent.

instrukcja 616-010.indb 121instrukcja 616-010.indb 121 2008-09-18 16:03:192008-09-18 16:03:19
