• Siesta® • Outdoor Unit
5
• Outdoor Unit • Pair application • AZQS-AV1
2 Specifications
Notes
(1) See separate drawings for electrical data
(2) Minimum Ssc (=Short-circuit power) value: Equipment complying with EN/IEC 61000-3-12: European/International Technical Standard setting the limits for harmonic currents
produced by equipment connected to public low-voltage systems with input current \>16A and ≤ 75A per phase
Refrigerant oil Type FVC50K Daphne FVC68D
Charged volume l 0.75 1.0
Piping
connections
Liquid Quantity 1
Type Flare connection
OD mm 9.52
Gas Quantity 1
Type Flare connection
OD mm 15.9
Drain Quantity 3
Type Hole
ID mm -
OD mm 26
Piping length Min. OU - IU m 5
OU - IU Max. m 50 75
System Equivalent m 70 95
Chargeless m 30
Additional refrigerant charge kg/m see installation manual 4PW68422-1
Level
difference
IU - OU Max. m 30.0
IU - IU Max. m 0.5
Heat insulation Both liquid and gas pipes
Defrost method Pressure equalising
Defrost control Temperature
Safety devices Item 01 High pressure switch
02 Fan motor thermal protection
03 Fuse
2-3 Electrical Specifications AZQS71AV1 AZQS100AV1 AZQS125AV1 AZQS140AV1
Power supply Name V1
Phase 1~
Frequency Hz 50
Voltage V 220-240
Voltage
range
Min. % -10
Max. % 10
Current Zmax List Complies to EN61000-3-11
Recommended fuses A 20 32
Wiring
connections
For power
supply
Remark see installation manual 4PW68422-1
For
connection
with indoor
Remark see installation manual 4PW68422-1
Power supply intake Outdoor unit only
2-2 Technical Specifications AZQS71AV1 AZQS100AV1 AZQS125AV1 AZQS140AV1
