![Samsung HT-A100 [5/59] Folie 5](/img/pdf.png)
Samsung HT-A100 [5/59] Folie 5
![Samsung HT-XA100 [5/59] Folie 5](/views2/1793022/page5/bg5.png)
5
2. General Feature
2. General Feature
POWER
(RM S]
5.1- CH : 600W (HT- XA100) / 2.1- CH : 300W (HT- A100) 3 ohm 10% THD
DSP
DOLBY Digital, DTS, Dolby Prologic II Surround Decoding
Virtual 5.1 Ch Surround For HT- A100
Play
Back
DVD Audio / Video, CD, DIVX, MP3, Photo, VCD
USA : Can’t play VCD Disc
1disc loading (slot- in type)
FM preset No RDS
V ID EO
Progressive Scan (480P- 720P- 1080i- 1080P)
IN&OU
T
USB host (mp3, WMA, WMV, JPG, MPG, DIVX Playback)
wireless ready
AUX 1 (3.5pi input) , AUX 2 Input (L/R Input)
(Optical) input
VIDEO OUT (COMPOSITE)
COMPONENT OUT
HDMI OUT
SPEA K E
R
2 way SPEAKER (tweeter +mid range)
4 Satellite XA100
2 satellite A100
Wall Mountable
