• Outdoor Units • R-410A • RZQ-B9V3B_RZQ-B8W1B
1
• Split Sky Air • Outdoor Units
2
1 Features
Outdoor Uni Split Sky RZQ-B9V3B_RZQ R-410A
• Outdoor units for pair, twin, triple, double twin application
• The Sky Air Inverter is developed for use in shops, restaurants and
small offices. This innovative Daikin unit provides a more
comfortable environment and offers great savings in energy
consumption to shop and office owners.
• The use of inverter type outdoor units results in an air conditioning
system with a high energy efficiency and very low sound level
• An inverter driven compressor allows the capacity to be adjusted
precisely to match variations in room and outside temperatures.
• During start up, the room can be cooled down or heated very quickly.
Once the temperature in the room has reached its set point, the low
power operation starts to save energy.
• Daikin outdoor units are neat and sturdy and can be mounted easily
on a roof or terrace or simply placed against an outside wall.
• Outdoor units are fitted with either a swing or scroll compressor,
renowned for low noise and high energy efficiency
• A special acryl precoated fin for anti-corrosion treatment on the heat
exchanger ensures greater resistance against severe weather
conditions
