This appliance is only meant for dry use - it is
not suitable for sucking in liquids and other
wet substances.
The appliance is suited for the extraction of
dry, combustible, harmful dusts on machines
and appliances in zone 22; dust class M and
B1 according to EN 60 335–2-69.
Restriction: No carcinogenic substance ex-
cept wood dust may be sucked in.
This appliance is suitable for industrial use.
Any other use other than the specified one will
be treated as improper use of the appliance.
1 Hose to the suction turbine
2 Handle for filter cleaning
3 Lid of filter chamber
4 Filter chamber
5 Connection neck for accessories
6 Manometer
7 Container for vaccuming material
8 Lever for unlocking the vacuuming ma-
terial container
9 Guiding rolls with fixed position brake
10 Sliding handle
11 Silencer
12 Diffuser
13 Control board
14 ON/OFF switch
15 Indicator lamp "Wrong rotation direction"
16 Indicator lamp "Mains voltage present"
Proper use
Device elements
Control elements IV 100/40 M B1, IV 100/55 M B1
15EN
