Daikin EK2VK0 [2/14] Access to the body machine

U.M. FWX(V/M)10AATV3 FWX(V/M)15AATV3 FWX(V/M)20AATV3

mm 14 16 18

EK2VK0 - EK3VK1

Pipeline diameter

List of hydraulic accessories

Pipeline diameter

- 2-way valve unit with thermo-electric head kit EK2VK0

for FWX(V/M)- series.

- 3-way deviator valve unit with thermo-electric head

deviator valve kit EK3VK1 for FWX(V/M)- series.

To avoid penalising the performance of the system the

water inlet and outlet must be as indicated in the various

figures.

For a rapid and correct assembly of the components

follow carefully the sequences described in the various

sections.

This instruction is an integral part of the booklet of the

appliance on which the kit is installed. Please consult

this booklet for general warnings and fundamental safety

rules.

The minimum internal diameter that must be respected for

the pipelines of the hydraulic connections varies according

to the model:

Access to the body machine

To access the inside of the machine, follow the procedures

below.

Remove the upper grill:- loosen the fixing screws

- loosen the fixing screws of the upper grill

- remove the grill

Remove the front grill:

- extract the grill until it is completely out of the seat

- tilt the grill

- slide outwards

Fixing screws

Upper grill

Front panel

Front grill
