Daikin EKRTCTRL1 [7/24] Air temperature probe assembly only for ekrtctrl1
![Daikin EKRTCTRL1 [7/24] Air temperature probe assembly only for ekrtctrl1](/views2/1795132/page7/bg7.png)
7
S
I
U
B
C
D
A
2.5
EN
- To position the temperature probe (ref. A):
- pass the probe through the hole on the shoulder (ref. B)
- insert the probe into the lower hole (ref. C)
- fix the probe on the relevant hook (ref. D)
Air temperature probe assembly (only for EKRTCTRL1)
