PARTS IDENTIFICATION
Refer to gures 1 to 9.
1. Main switch
2. Handle
3. Lance rest
4. Warning plates. Inform on residual risks and PPE
to be used
5. Identication plate. Indicates the serial number,
guaranteed sound power value (in compliance
with Directive 2000/14/EC) and main technical
characteristics
6. Electric power cable
7. Fuel tank cap
8. Pressure adjustment knob
9. Water softener tank cap
10. Support for the power cord and the delivery
hose
11. Detergent tank cap (models with box)
12. Hose reel (optional)
13. Pressure gauge
14. Knob for rewinding the hose reel (optional)
15. Hose reel locking handle (optional)
16. Water outlet connector
17. Water inlet connector
18. Water inlet lter
19 Pump
20. Exhaust
21. Lance pipe (models without box)
22. Cleaner gun lever
23. Safety catch on cleaner gun lever
24. Cleaner gun (models EXTRA)
25. Water inlet hose support
26. Seal for water inlet hose suppor
27. Nozzle support head (models with box)
28. Cover to reach the tanks and lifting point
29.
Lance pipe (models with box)
30. Nozzle holder head (models without box)
MEANING OF GRAPHIC SYMBOLS USED
“0” position (o) of main switch (1).
“1” position (on) of main switch (1), with cold water operation of high pressure
cleaner enabled.
“1” position (on) of main switch (1), with hot water operation of high pressure cleaner
enabled. With pressures less than 32 bar/464 psi it also enables steam operation
(only EXTRA).
SAFETY DEVICES
Amperometric protector.
This safety device stops the high-pressure cleaner in the event of electrical overcurrent.
“EXTRA versions: If the amperometric protector trips, the warning light (46) will light up. Should this
31. Nozzle cleaning pin
32. Lifting point
33. Door to reach the: water inlet lter, pressure
regulation, pump oil dipstick
34. Knob for adjusting detergent
35. High pressure hose
36. High pressure hose quick t connector
37. Screw of the door to reach the: water inlet lter,
pressure regulation, pump oil dipstick
38. Optional hose reel xing point
39. Swivel wheel
40. Swivel wheel brake
41. Knob for temperature adjustment
42. Power ON warning light
43. High pressure hose connector
44. Low fuel warning light
45. Timed Shutdown warning light
46. Thermal overload warning light
47. Leakage Detected warning light
48. Steam Shutdown warning light
49. Burner Malfunction warning light
50. Suction hose grip
51. Dipstick for pump oil
52. Spray gun (models BASIC and CLASSIC)
53. Detergent suction hose
54. External detergent tank suction coupling
55. External detergent tank suction cap
56. External detergent tank suction hose tting
57. External detergent tank suction hose
58. External detergent tank suction hose lter
59. Fuel ll up lter
60. Water inlet lter body
61. Water inlet lter cartridge
62. Water inlet lter cup
