Installer reference guide

Daikin Altherma R Hybrid

English

Installer reference guide

Daikin Altherma R Hybrid

CHYHBH05AA

CHYHBH08AA

EHYKOMB33A

Содержание

Chyhbh05aa chyhbh08aa 1
Daikin altherma r hybrid 1
Ehykomb33a 1
Installer reference guide 1
About the box 9 2
About the documentation 8 2
About the product 8 2
About the units and options 11 2
General safety precautions 3 2
Installation 22 2
Installer reference guide 2
Preparation 15 2
Table of contents 2
About the documentation 3
Commissioning 70 3
Configuration 47 3
Danger 3
Danger risk of electrocution 3
Disposal 84 3
Field settings table 101 3
General safety precautions 3
Glossary 100 3
Hand over to the user 75 3
Indicates a situation that could result in electrocution 3
Indicates a situation that results in death or serious injury 3
Maintenance and service 75 3
Meaning of warnings and symbols 3
Operation 69 3
Technical data 85 3
The installation of the system and all activities described in the installation manual and the installer reference guide must be performed by an authorised installer 3
The original documentation is written in english all other languages are translations 3
The precautions described in this document cover very important topics follow them carefully 3
Troubleshooting 78 3
For the installer 4
General 4
General safety precautions 4
Installation site 4
General safety precautions 5
Refrigerant 5
Electrical 6
General safety precautions 6
Gas exhaust 7
General safety precautions 7
Local legislation 7
About the documentation 8
About the product 8
About this document 8
Installer reference guide at a glance 8
About the box 9
Indoor unit 9
Overview about the box 9
To remove the accessories from the indoor unit 9
To unpack the indoor unit 9
A b c d e 10
About the box 10
Gas boiler 10
To remove the accessories from the gas boiler hybridpair multi 10
To unpack the gas boiler 10
About the units and options 11
Identification 11
Identification label gas boiler 11
Identification label indoor unit 11
M n o p q 11
Overview about the units and options 11
About the units and options 12
Combining units and options 12
Possible options for the indoor unit 12
About the units and options 13
Possible options for the gas boiler 13
About the units and options 14
Installation site requirements of the indoor unit 15
Overview preparation 15
Possible combinations of indoor unit and domestic hot water tank 15
Possible combinations of indoor unit and outdoor unit 15
Preparation 15
Preparing the installation site 15
Preparation 16
1 42 kg are not subjected to any requirements to the installation room 17
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 17
Information 17
Installer reference guide 17
Kg you need to comply with the minimum floor area requirements as described in the following flow chart the flow chart uses the following tables 15 table 1 maximum refrigerant charge allowed in a room indoor unit 4 90 15 table 2 minimum floor area indoor unit 4 92 and 15 table 3 minimum venting opening area for natural ventilation indoor unit 4 93 17
Preparation 17
Systems with a total refrigerant charge 17
Preparation 18
Preparing refrigerant piping 18
Preparing water piping 18
Refrigerant piping insulation 18
Refrigerant piping requirements 18
Water circuit requirements 18
A b d e 19
Preparation 19
A b d e h g 20
C d a b 20
Formula to calculate the expansion vessel pre pressure 20
Preparation 20
To check the water volume and flow rate 20
About preparing electrical wiring 21
Changing the pre pressure of the expansion vessel 21
Preparation 21
Preparing electrical wiring 21
To check the water volume examples 21
7 8 9 10 14 15 22
Installation 22
Overview installation 22
Overview of electrical connections except external actuators 22
Overview of electrical connections for external and internal actuators 22
About opening the units 23
Installation 23
Opening the units 23
To open the gas boiler 23
To open the switch box cover of the gas boiler 23
To open the switch box cover of the indoor unit 23
About mounting the indoor unit 24
Installation 24
Mounting the indoor unit 24
Precautions when mounting the indoor unit 24
To install the indoor unit 24
Installation 25
Mounting the gas boiler 25
To install the condensate trap 25
To install the gas boiler 25
75 mm ø22 mm 26
Condensate pipe work 26
Condensate pump 26
Installation 26
Internal connections 26
Ø22 mm 26
About connecting the refrigerant piping 27
Connecting the refrigerant piping 27
External connections 27
Installation 27
Precautions when connecting the refrigerant piping 27
Ø22 mm 27
A b c d e 28
Guidelines when connecting the refrigerant piping 28
Installation 28
Pipe bending guidelines 28
To braze the pipe end 28
To flare the pipe end 28
To handle the stop valve 28
Using the stop valve and service port 28
Installation 29
To connect the refrigerant piping to the indoor unit 29
To handle the service cap 29
To handle the stem cap 29
To open close the stop valve 29
Usage of reducers to connect the piping to the outdoor unit 29
About charging refrigerant 30
About checking the refrigerant piping 30
Charging refrigerant 30
Checking the refrigerant piping 30
Installation 30
Precautions when checking the refrigerant piping 30
To check for leaks 30
To perform vacuum drying 30
About the refrigerant 31
Installation 31
Precautions when charging refrigerant 31
To charge additional refrigerant 31
To determine the additional refrigerant amount 31
To determine the complete recharge amount 31
About connecting the water piping 32
Connecting the water piping 32
Connecting the water piping of the indoor unit 32
Installation 32
Precautions when connecting the water piping 32
To connect the water piping for space heating 32
To fix the fluorinated greenhouse gases label 32
Connecting the water piping of the gas boiler 33
Installation 33
To connect the water piping for domestic hot water not applicable for switzerland 33
To connect the water piping for space heating 33
About connecting the electrical wiring 34
Connecting the electrical wiring 34
Guidelines when connecting the electrical wiring 34
Installation 34
Precautions when connecting the electrical wiring 34
To connect the water piping for domestic hot water applicable for switzerland 34
To fill the domestic hot water tank 34
To fill the domestic water circuit of the gas boiler 34
To fill the space heating circuit 34
To insulate the water piping 34
Installation 35
To connect the electrical wiring on the indoor unit 35
To connect the main power supply of the indoor unit 35
Installation 36
To connect the communication cable between gas boiler and indoor unit 36
To connect the main power supply of the gas boiler 36
Installation 37
To connect the user interface 37
Installation 38
To connect the alarm output 38
To connect the domestic hot water pump 38
To connect the shut off valve 38
To connect the space heating on off output 38
Connecting the boiler to the flue gas system 39
Connecting the gas piping 39
Installation 39
To connect the gas pipe 39
To connect the safety thermostat normally closed contact 39
Installation 40
To change the 60 100 concentric connection to a dual pipe connection 40
To change the gas boiler to 80 125 concentric connection 40
Appliance categories and pipe lengths 41
Calculate the total piping length 41
Installation 41
R d 1 r d 0 41
Installation 42
Applicable materials 43
Installation 43
L2 1 l1 11 43
Fitting a horizontal flue system 44
Flue pipe position 44
Installation 44
Insulation of the gas exhaust and air intake 44
Fitting a vertical flue system 45
Flues in voids 45
Installation 45
Plume management kit 45
Finishing the gas boiler installation 46
Finishing the indoor unit installation 46
Finishing the outdoor unit installation 46
Installation 46
To close the gas boiler 46
To close the indoor unit 46
To close the outdoor unit 46
To finish the outdoor unit installation 46
To install the cover plate 46
To perform an air purge on the gas supply 46
Configuration 47
Indoor unit 47
Overview configuration 47
To access the most used commands 47
To connect the pc cable to the switch box 47
00 04 08 0c 48
01 05 09 0d 48
03 07 0b 0f 48
06 0a 0e 48
Cancel ok 48
Configuration 48
Send data 48
To copy the system settings from the first to the second user interface 48
U5 auto address 48
2013 jan tue 49
Basic configuration 49
Configuration 49
Confirm layout please confirm the system layout the system will restart and will be ready for first startup 49
Date what is the date today 49
Language select the desired language 49
Ok cancel 49
Quick wizard language time and date 49
Quick wizard set the system layout after first power on 49
Quick wizard standard 49
Standard options capacities confirm layout 49
System layout 49
To copy the language set from the first to the second user interface 49
What is the current time time 49
Configuration 50
Quick wizard options 50
Configuration 51
Configuration 52
Space heating control 52
Configuration 53
Configuration 54
Advanced configuration optimization 55
Configuration 55
Contact helpdesk number 55
Domestic hot water control 55
Space heating operation advanced 55
Configuration 56
Configuration 57
Configuration 58
Domestic hot water control advanced 58
Configuration 59
Configuration 60
Heat source settings 60
System settings 60
Configuration 61
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 62
Configuration 62
Installer reference guide 62
Menu structure overview user settings 62
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 63
Configuration 63
Demand pcb settings are shown but are not applicable for this unit settings shall not be used or changed 63
Depending on the selected installer settings and unit type settings will be visible invisible 63
External kwh meter settings are shown but are not applicable for this unit settings shall not be used or changed 63
Gas meter settings are shown but are not applicable for this unit settings shall not be used or changed 63
Information 63
Installer reference guide 63
Menu structure overview installer settings 63
2 7 5 6 3 4 8 64
A b c f e d 64
Basic configuration 64
Configuration 64
Domestic hot water comfort function 64
Domestic hot water temperature 64
Frost protection function 64
Gas boiler 64
Keep hot function 64
Maximum space heating supply temperature 64
Overview configuration 64
To reset the gas boiler 64
To set the parameters via the service code 64
To turn on off the gas boiler 64
Configuration 65
Configuration 66
Maximum space heating power setting 66
About the carbon dioxide setting 67
Configuration 67
To change to a different type of gas 67
Configuration 68
Domestic hot water 69
Flow resistance graph for appliance domestic hot water circuit 69
Heating 69
Operation 69
Operation modes 69
Overview operation 69
Checklist before commissioning 70
Commissioning 70
Overview commissioning 70
Precautions when commissioning 70
Air purge function 71
Checklist during commissioning 71
Commissioning 71
To check the minimum flow rate 71
To perform a wiring error check 71
18 tue 72
Air purge 72
Commissioning 72
To interrupt air purge 72
To perform a manual air purge 72
To perform a test run 72
To perform an automatic air purge 72
Commissioning 73
H 1 36h 2 73
Possible actuator test runs 73
To perform an actuator test run 73
Underfloor heating screed dryout 73
Commissioning 74
Screed dryout 74
To interrupt an underfloor heating screed dryout 74
To perform a gas pressure test 74
To perform a test run on the gas boiler 74
To perform an underfloor heating screed dryout 74
To program an underfloor heating screed dryout schedule 74
To readout the status of an underfloor heating screed dryout 74
Checklist for yearly maintenance of the indoor unit 75
Hand over to the user 75
Maintenance and service 75
Maintenance safety precautions 75
Opening the indoor unit 75
Overview maintenance and service 75
Maintenance and service 76
To disassemble the gas boiler 76
Maintenance and service 77
To assemble the gas boiler 77
To clean the inside of the gas boiler 77
Overview troubleshooting 78
Precautions when troubleshooting 78
Solving problems based on symptoms 78
Symptom the unit is not heating or cooling as expected 78
Troubleshooting 78
Symptom the compressor does not start space heating 79
Symptom the pressure relief valve opens 79
Symptom the pump is making noise cavitation 79
Symptom the system is making gurgling noises after commissioning 79
Troubleshooting 79
0 symptom boiler abnormality detection hj 11 error 80
1 symptom boiler hydrobox combination abnormality ua52 error 80
Symptom tank disinfection function is not completed correctly ah error 80
Symptom the pressure at the tapping point is temporarily unusually high 80
Symptom the space is not sufficiently heated at low outdoor temperatures 80
Symptom the water pressure relief valve leaks 80
Troubleshooting 80
2 symptom the burner does not ignite 81
3 symptom the burner ignites noisily 81
4 symptom the burner resonates 81
5 symptom no space heating by the gas boiler 81
6 symptom the power is reduced 81
7 symptom space heating does not reach the temperature 81
8 symptom hot water does not reach the temperature no tank installed 81
Troubleshooting 81
9 symptom hot water does not reach the temperature tank installed 82
Error codes of the indoor unit 82
Error codes overview 82
Solving problems based on error codes 82
Troubleshooting 82
Error codes of the gas boiler 83
Troubleshooting 83
Disposal 84
Overview disposal 84
To pump down 84
To start and stop forced cooling 84
D082238 1b 85
Piping diagram indoor unit 85
Technical data 85
Technical data 86
Wiring diagram indoor unit 86
Technical data 87
A1p x9a 88
D107996 88
Domestic hot water tank 88
Electrical connection diagram for more details please check the unit wiring 88
Gas boiler 88
Only for heat pump convector 88
Only for krcs01 1 or ekrsca1 88
Only for krp1hb 88
Only for krtets 88
Only for krtr wireless room thermostat 88
Only for krtw wired room thermostat 88
Only for ksrps3 option 88
Optional parts khwp 88
Power supply 88
Standard parts 88
Technical data 88
Technical data 89
Wiring diagram gas boiler 89
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 90
Installer reference guide 90
Table 1 maximum refrigerant charge allowed in a room indoor unit 90
Technical data 90
Technical data 91
1 42 kg are not subjected to any requirements to the installation room 92
2 5 kg consider 92
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 92
For intermediate 92
For intermediate h values i e when h is between 2 h values from the table consider the value that corresponds to the lower h value from the table if h 950 mm consider the value that corresponds to h 900 mm 92
H the height measured from the floor to the bottom of the casing 92
H the height measured from the floor to the flare nut 92
In cases where h 600 mm h is always considered to be 600 mm as specified in iec 60335 2 40 2013 a1 2016 clause gg2 92
Information 92
Installer reference guide 92
Is between 2 92
Systems with a total refrigerant charge 92
Table 2 minimum floor area indoor unit 92
Technical data 92
Value from the table if 92
Values from the table consider the value that corresponds to the higher 92
Values i e when 92
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 93
Installer reference guide 93
Table 3 minimum venting opening area for natural ventilation indoor unit 93
Technical data 93
1500 mm 94
2 kg and dm 0 5 kg consider dm 0 kg 94
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 94
Following graphics are possible examples about minimum venting opening area for natural ventilation 94
For intermediate dm values i e when dm is between 2 dm values from the table consider the higher dm value from the table for 3mxm52 with 94
For intermediate h values i e when h is between 2 h values from the table consider the value that corresponds to the lower h value from the table if h 950 mm consider the value that corresponds to h 900 mm 94
H height measured from the floor to the bottom of the casing 94
H height measured from the floor to the flare nut 94
In case of a different configuration is used do not deviate from requirements mentioned in 6 preparation 4 15 94
In cases where h 600 mm h is always considered to be 600 mm as specified in iec 60335 2 40 2013 a1 2016 clause gg2 94
Information 94
Installer reference guide 94
Mm 20 mm 94
Technical data 94
Warning 94
B l min 95
Esp curve indoor unit 95
Technical data 95
Gas category and supply pressure 96
General 96
Technical data 96
Technical specifications gas boiler 96
Technical data 97
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 98
Gas boiler system commissioning checklist 98
Installer reference guide 98
Technical data 98
This commissioning checklist is to be completed in full by the competent person who commissioned the boiler as a means of demonstrating compliance with the appropriate building regulations and then handed to the customer to keep for future reference 98
Chyhbh05 08aa ehykomb33a daikin altherma r hybrid 4p471761 1c 2019 9 99
Installer reference guide 99
Service 01 99
Service 02 99
Service 03 99
Service 04 99
Service 05 99
Service 06 99
Service 07 99
Service 08 99
Service 09 99
Service 10 99
Service record 99
Technical data 99
Glossary 100
Field settings table 101
Field settings table 102
P471775 1 2016 2 chyhbh 102
Chyhbh 4p471775 1 2016 2 103
Field settings table 103
Field settings table 104
P471775 1 2016 2 chyhbh 104
Chyhbh 4p471775 1 2016 2 105
Field settings table 105
Field settings table 106
P471775 1 2016 2 chyhbh 106

Daikin CHYHBH08AAV32 Руководство по применению для установщика онлайн

Содержание

Похожие устройства
