Daikin ERRQ016AAV1 [162/459] Specifications
![Daikin ERRQ014AAV1 [162/459] Specifications](/views2/1799160/page162/bga2.png)
• Heating • Daikin Altherma
159
• Daikin Altherma Low Temperature • Outdoor units • ERHQ011-016BAW1
2 Specifications
10
2
2-1 NOMINAL CAPACITY AND NOMINAL INPUT ERHQ011BAW1 ERHQ014BAW1 ERHQ016BAW1
For combination
indoor units + outdoor
units
Indoor Units EKHBH016BA
Condition 1 Heating capacity Nominal kW 11.32 14.50 16.05
Heating PI Nominal kW 2.54 3.33 3.73
COP Nominal 4.46 4.35 4.30
Nominal Capacity Heating capacity Nominal kW 10.98 13.57 15.11
Heating PI Nominal kW 3.15 4.12 4.60
COP Nominal 3.48 3.29 3.29
For combination
indoor units + outdoor
units
Indoor Units EKHBX016BA
Condition 1 Heating capacity Nominal kW 11.32 14.50 16.05
Cooling capacity Nominal kW 15.05 16.06 16.76
Heating PI Nominal kW 2.54 3.33 3.73
Cooling PI Nominal kW 4.44 5.33 6.06
COP Nominal 4.46 4.35 4.30
EER Nominal 3.39 3.01 2.76
Nominal Capacity Heating capacity Nominal kW 10.98 13.57 15.11
Cooling capacity Nominal kW 11.72 12.55 13.12
Heating PI Nominal kW 3.15 4.12 4.60
Cooling PI Nominal kW 4.22 5.00 5.65
COP Nominal 3.48 3.29 3.29
EER Nominal 2.78 2.51 2.32
Notes Condition 1: cooling Ta 35×C - LWE 18×C (DT = 5×C) - heating Ta DB/WB 7×C/6×C - LWC 35×C (DT
= 5×C)
Condition 2: cooling Ta 35×C - LWE 7×C ( DT = 5×C ) - heating Ta DB/WB 7×C/6×C - LWC 45×C ( DT
= 5×C )
2-2 TECHNICAL SPECIFICATIONS ERHQ011BAW1 ERHQ014BAW1 ERHQ016BAW1
Casing Colour Ivory white
Material Painted galvanised steel plate
Dimensions Unit Height mm 1,345
Width mm 900 900 900
Depth mm 320 320 320
Packing Height mm 1,524
Width mm 980 980 980
Depth mm 420 420 420
Weight Unit kg 108 108 108
Packed Unit kg 120 120 120
Packing Material EPS
Carton
Wood
PE (Straps)
Weight kg 12 12 12
Heat Exchanger Dimensions Length mm 857 857 857
Nr of Rows 2 2 2
Fin Pitch mm 1.4 1.4 1.4
Nr of Passes 5 5 5
Face Area m² 1.131 1.131 1.131
Nr of Stages 60 60 60
Tube type Hi-XSS(8)
Fin Type WF fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller
Quantity 2 2 2
Discharge direction Horizontal
Motor Quantity 2 2 2
Model Brushless DC motor
101727_BW_EN_004_464_IC.pdf 163 9/06/2010 14:54:27
