31
NOTE:
Once the set temperature has been reached, the
HEATING control lamp goes off. The power on lamp
remains on and shows that the device is working.
8. Now ll the deep-fry basket. Please ensure that the basket
is not lled above the hot fat. Open the lid and insert the
basket with the items to be fried carefully into the recess.
9. Now close the lid. Release the handle (by pushing the but-
ton (12) on the handle). The deep-fry basket is now in the
hot fat.
NOTE:
• During the deep-frying process the HEATING control
lamp switches on and off several times. This is nor-
mal and it indicates that the temperature is controlled
by the thermostat and is being maintained.
• The frying times are to be found on the packaging of
the food or in the recipe.
10. After the frying time has expired, you can allow the oil
to drain off the deep-fried food. To do so, reach into the
recess and pull the handle (13) up, until it latches. This will
lift the basket.
11. Open the lid carefully.
WARNING:
As it is possible that hot steam will be released.
12. Now remove the deep-frying basket.
Switching Off
• Set the temperature regulator to the minimum setting (0).
• Switch the appliance off at the main switch (O).
• Remove the mains plug from the socket.
• Allow the frying oil a considerable time to cool down. Before
continuing to use the full frying pot, please ensure that it is
no longer at a dangerous temperature.
Cleaning
WARNING:
• Always pull out the plug from the mains socket before
cleaning and wait until the unit has cooled down.
• Under no circumstances should you immerse the device
in water for cleaning purposes. Otherwise this might result
in an electric shock or re.
CAUTION:
• Do not use a wire brush or any abrasive items.
• Do not use any acidic or abrasive detergents.
• The lid of the deep fryer can be removed. This makes it
easier to clean.
• Pull out the condensation tray on the back of the appliance
to empty it. Replace it afterwards.
• Pour out any used oil from the side.
• Clean the fat container, the lid and the housing with a damp
cloth and if necessary domestic washing-up liquid.
• Deep frying basket can be cleaned in the normal way in
soapy water.
• Ensure that the parts are completely dry before re-using the
appliance and before storage.
Changing the Odour and Fat Vapour Filter
The lter in the lid can be replaced.
• Remove lter cover (3).
• Replace the lter.
• Then reassemble the cover.
NOTE:
When these lters have been used up it is possible to cut
universal lters to size, e.g. from cooker hoods.
Technical Data
Model: ....................................................................... FR 2223 CB
Power supply: ...........................................................230 V, 50 Hz
Power consumption: ......................................................... 1800 W
Protection class: ........................................................................... I
Filling quantity: ..................................................................max. 2 l
Net weight: .........................................................................2.45 kg
Subject to technical changes without prior notice!
This device has been tested according to all relevant current
CE guidelines, such as electromagnetic compatibility and low
voltage directives, and has been constructed in accordance
with the latest safety regulations.
Meaning of the “Dustbin” Symbol
Protect our environment: do not dispose of electrical equipment
in the domestic waste.
Please return any electrical equipment that you will no longer
use to the collection points provided for their disposal.
This helps avoid the potential effects of incorrect disposal on
the environment and human health.
This will contribute to the recycling and other forms of reutilisa-
tion of electrical and electronic equipment.
Information concerning where the equipment can be disposed
of can be obtained from your local authority.
