![Daikin ALB04LBMNADBT00 [12/12] Daikin applied europe s p a](/views2/1801481/page12/bgc.png)
Modular-Light AHU
User Manual
12
Alarm Code Alarm String Description
FL09
Fire alarm
Fire alarm active:
fire detector device detected fire presence. Unit enters fire mode.
FL11
Supply temperature
sensor fault
Supply temperature sensor error:
measured temperature out of the allowable range or error condition on
the temperature sensor (not connected or broken).
FL12
Return temperature
sensor fault
Return temperature sensor error:
measured temperature out of the allowable range or error condition on
the temperature sensor (not connected or broken).
FL13
Outside temperature
sensor fault
Outside temperature sensor error:
measured temperature out of the allowable range or error condition on
the temperature sensor (not connected or broken).
FL14
Exhaust temperature
sensor fault
Exhaust temperature sensor error:
measured temperature out of the allowable range or error condition on
the temperature sensor (not connected or broken).
FL15
Supply fan sensor
fault
Supply fan pressure sensor error:
measured pressure out of the allowable range or error condition on the
pressure sensor (not connected or broken).
FL16
Return fan sensor
fault
Return fan pressure sensor error:
measured pressure out of the allowable range or error condition on the
pressure sensor (not connected or broken).
The present publication is drawn up by of information only and does not constitute an offer binding upon Daikin Applied Europe S.p.A..
Daikin Applied Europe S.p.A. has compiled the content of this publication to the best of its knowledge. No express or implied warranty is
given for the completeness, accuracy, reliability or fitness for particular purpose of its content, and the products and services presented
therein. Specification are subject to change without prior notice. Refer to the data communicated at the time of the order. Daikin Applied
Europe S.p.A. explicitly rejects any liability for any direct or indirect damage, in the broadest sense, arising from or related to the use
and/or interpretation of this publication. All content is copyrighted by Daikin Applied Europe S.p.A..
DAIKIN APPLIED EUROPE S.p.A.
Via Piani di Santa Maria, 72 - 00072 Ariccia (Roma) - Italia
Tel: (+39) 06 93 73 11 - Fax: (+39) 06 93 74 014
http://www.daikinapplied.eu
