Modular-Light AHU

User Manual

6. By pressing the OK button month is saved and day blinks, then set the day with the + and -

7. By pressing the OK button month and day are saved, the display returns to the time

8. By Pressing PROG button the display returns to normal view

The display automatically returns to normal view when the PROG button is not pressed within one

minute.

Time Scheduler settings

The scheduler is working with 7 weekdays and 6 switches can be set up for each day. By setting up

the switch, the user can set a time point and select one operation in Auto mode.

To set the time scheduler follow these steps:

1. Hold PROG button to enter time scheduler setting. In time scheduler, button is used to

cancel, while OK button to confirm.

2. Pressing button + or -, the number of corresponding weekday will blink on screen. Holding

button + or -, cursor will keep moving on the weekdays in a cyclic way.

3. When cursor moves onto one weekday, pressing button will select this number or deselect

it. When one weekday is selected, the day will be displayed on screen constantly. More than one

weekday can be selected.
