8 Troubleshooting
Installation and operation manual
28
LRMEQ+LRLEQ3+4BY1
Air-cooled refrigeration condensing unit
4P545024-1 – 2018.09
Code Description Criteria Times of
retry
Output signal Cause Solution
Wet operation from refrigeration
suction pipe
Suction superheat <5K AND discharge
superheat <15K AND discharge temperature
<60°C, continuously for 10 minutes
0 Caution
▪
Excessive frost formation on indoor
side
▪
Wrong selection of expansion valves
▪
Adjust defrost cycle
▪
Select the correct type of expansion
valve
In addition to above conditions (for caution):
discharge superheat <15K for 6 hours
0 Warning
Wet operation from injection pipe Suction superheat ≥5K AND discharge
superheat <15K AND discharge temperature
<60°C, continuously for 90 minutes
0 Caution
▪
Defective expansion valve, suction pipe
thermistor, or subcool heat exchanger
outlet thermistor
▪
Refrigerant overcharge
▪
Replace defective component
▪
Adjust refrigerant charge
In addition to above conditions (for caution):
discharge superheat <15K for 6 hours
0 Warning
3‑sensor error When 3 or more sensors detect abnormality 0 Warning
▪
Faulty connection of sensor
▪
Defective sensor or outdoor unit PCB
▪
Connect the sensor properly
▪
Replace defective component
High pressure switch failure No continuity of high pressure switch 0 Warning
▪
Faulty connection of switch
▪
Defective swith or outdoor unit PCB
▪
Connect the switch properly
▪
Replace defective component
Outdoor fan motor signal failure Abnormal position of signal of 1 fan motor 4 Caution
▪
Abnormal fan motor signal (circuit
error)
▪
Broken, short, or disconnected
connector of fan motor connection
cable
▪
Defective inverter PCB
▪
Ensure correct connection
▪
Replace the fan motor
▪
Replace the inverter PCB
Abnormal position of signal of 2 fan motors 4 Warning
Outdoor air thermistor failure Open circuit or shortcircuit 0 Caution
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Discharge thermistor failure Open circuit or shortcircuit 0 Warning
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Suction thermistor failure Open circuit or shortcircuit 0 Caution
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Heat exchanger inlet thermistor
failure
Open circuit or shortcircuit 0 Warning
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Heat exchanger outlet thermistor
failure
Open circuit or shortcircuit 0 Warning
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
High pressure sensor failure Open circuit or shortcircuit 0 Caution
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Low pressure sensor failure Open circuit or shortcircuit 0 Warning
▪
Faulty connection of sensor
▪
Defective sensor
▪
Connect the sensor properly
▪
Replace defective component
Inverter PCB malfunction IGBT error 0 Warning
▪
Defective inverter PCB
▪
Check for external causes (e.g. EMI
noise), or replace the inverter PCB.
Radiation fin temperature rise 93°C 9 Warning
▪
Fin temperature rise because of
inverter malfunction
▪
Fin temperature rise because of short
circuit
▪
Fin thermistor malfunction
▪
Remove any obstacles that block the
passage of air to the outdoor unit
▪
Check connection on PCB
▪
Replace defective component
Inverter compressor
instantaneous overcurrent
— 9 Warning — —
Inverter compressor overcurrent ≥16.1A 9 Warning — —
Defective inverter compressor
startup failure
— 4 Warning — —
Transmission error between
control PCB and inverter PCB
Transmission failure between main PCB and
inverter PCB
No limit Caution Defective connection between main and
inverter PCB
Replace defective component
Inverter compressor power
voltage imbalance
— 9 Warning Unbalanced power supply voltage Check if power supply is within range
Radiation fin thermistor Radiation fin thermistor open circuit or short
circuit
No limit Caution Defective radiation fin thermistor, inverter
PCB, inverter compressor, or fan motor
Replace defective component
Reversed phase / Open phase Reversed phase or open phase 0 Warning Faulty connection of phase order to power
supply terminal X1M
Make sure the phase order to X1M is ok
Inverter compressor abnormal
power voltage
— 9 Warning Insufficient power supply voltage Make sure there is sufficient power supply
voltage
