Bomann MWG 2215 EB [20/30] Avoiding fire hazards with built in appliances
![Bomann MWG 2215 EB [20/30] Avoiding fire hazards with built in appliances](/views2/1080226/page20/bg14.png)
20
Symbols on the control panel
Symbol
Meaning/
function
Symbol
Meaning/
function
Microwave
Child-prooflock
activated
Defrosting Auto function
Grill Weight in grams
Microwave+grill
Programmed
Start
Powerhigh/low
Avoiding Fire Hazards with Built-in Appliances
Alwaysobservetheinstructionscontainedinthesection“Installa-
tion Instructions”.
• Donotremovethefeetontheundersideofthedevice.
• Useonlythemountingmaterialssuppliedfortheinstallation.
• Wheninstallingthemicrowaveoven,pleaseadheretothe
dimensions shown in drawings 1 and 2.
• Therearwallofthecupboardhastoberemoved!
• Thereisaventilationslotatthebottomedgeofthemounting
frame. Keep the ventilation slots free at all times.
Installation Accessories
Item Designation Number
A
Adjustment screw 1
B
Mounting frame 1
C
Screw 1
D
Dummyplug 1
Installation Instructions
This microwave oven must be installed in a tall or wall cupboard.
Pleasenotethefollowinginstructions:
• Removeeverythingthatisfragilefromtheadjacentcup-
boards.
• Forinstallationthecabinetmustmeetthefollowingcondi-
tions:
• Thecupboardmustnotcontainanycracks,splintersor
other damage. All connections must be stable.
• Thecupboardmustbedesignedforaminimumloadof
40kg.
• Themicrowaveovenmustbeinstalledataheightofat
least 85 cm.
• Therearwallofthecupboardhastoberemovedsothat
the microwave oven is ventilated!
• Thethicknessofthecupboardwallmustbeatleast
19 mm.
• Wallcupboardsmustbeanchoredrmlyinthewallwith
atleast2screws.Checkthestabilitybyattachinganap-
propriate weigh.
• Inthecaseofwallcupboardstheinstallationdepthofthe
cupboard has to be at least 320 mm.
CAUTION:
Do not install the device above a cooker!
• Wheninstallingthedeviceitmustbeensuredthatthereisa
powersocketwithinreach.
• Themainssocketmustbewithineasyreach,sothattheplug
canbequicklyremovedinanemergency.
• Important! Do not connect the device to the mains power
supplyuntilafterinstallation!
WARNING:
• Pleaseadheretothedimensionsstatedintheinstallation
instructions.
• Theinstallationaccessoriessuppliedshouldbeused.
• Ifscrewsareinsertedtoodeeply(screwstoolong)thismay
damage the device or represent a hazard to the user or oth-
ers.
Dimensions of the Built-in Cupboard
Makeabuilt-incupboardoranicheinaccordancewiththefollow-
ingdimensionaldrawings.Figure1isforwallcupboards,gure2
for tall cupboards.
Installation (Figures3to6)
• Screwtheadjustmentscrew(A)completelyintotheupperair
duct(E).
• Putthemicrowaveinthebuilt-incupboard.
• Nowunscrewtheadjustmentscrewuntilitisabout1mm
below the top of the cupboard.
NOTE:
This prevents the microwave oven from tilting over in the
cupboard.
• Pushthemicrowavecompletelyintothecupboardandpull
the connection cables in after it.
• Alignthemicrowavewiththecentreofthecupboard.
• Securethemicrowavewiththescrew(C)andsealtheopen-
ingwiththedummyplug(D).
