5
05/2012
INSTALL WASHING MACHINE
■ Unpacking the washing machine
Unpack your washing machine and check for transport damage. Check that all accessories are sup-
plied (as shown on page 4). In case of transport damage or missing accessories please contact your
local distributor directly.
■ Dispose the packing materials
The packing materials of this machine may be dangerous for kids. Please dispose them properly and
avoid easy touch by kids. Please dispose the related packing materials according to the relevant local
regulations. Please do no throw the packing materials away together with the other daily living rub-
bishes.
■ Remove transport bolts
Before using this washing machine, transport bolts must be removed from the
backside of this machine. Please take the following steps to remove the bolts:
1. Loosen all bolts with spanner and then remove them.
2. Insert the supplied stoppers.
3. Keep the transport bolts properly for future use.
■ Select the location
Before installing the washing machine, the location characterized as follows shall be selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the following figure
"Adjust Leg")
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0°C;
- Keep far away from the heat resources such as coal or gas.
Important: Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
If the machine nevertheless will be install on a carpet floor pls. take care that the floor staples do not
close or block the ventilation slots at the bottom of the machine.
On wood floor as you can see on old buildings please put a 22 mm wood plate or a 4 mm steel plate
under the machine because the washing machine will becomes in swinging spinning. If the washing
machine is standing on a plinth please make sure, that you will protect the washing machine accord-
ingly.
■ Adjust feet
1. When positioning the washing machine, please first check if the legs are closely attached to the
cabinet. If not, please turn them to their original positions with hand or
spanner and tighten the nuts with spanner.
2. After positioning the washing machine, press four corners on top cover of
washing machine in sequence. If the washing machine is not stable
when being pressed, this leg shall be adjusted.
3. Ensure the positioning status of washing machine. Loosen the lock nut
with spanner and turn the leg with hand until it closely contacts with the
floor. Press the leg with one hand and fasten the nut closely to the cabinet with the other hand.
4. Now check stability. Repeat steps 2 and 3 if necessary.
Please note: Generally only one foot has to be adjusted. In case the problem is at the rear you can
also adjust the diagonal front foot for the same effect.
■ Connect the inlet hose
Connect the inlet hose as shown in the figure.
Use the new included inlet hose to connect the machine at the water supply.
