HPP EL 152/100 (800 об/мин) [4/17] Bell housing for hydraulic motor kit campana para acoplamiento a motores hidráulicos glocken set für kopplung mit hydraulikmotoren kit campana per accoppiamento a motori idraulici kit cloche pour accouplement à des moteurs hydrauliques
![HPP EL 152/100 (800 об/мин) [4/17] Bell housing for hydraulic motor kit campana para acoplamiento a motores hidráulicos glocken set für kopplung mit hydraulikmotoren kit campana per accoppiamento a motori idraulici kit cloche pour accouplement à des moteurs hydrauliques](/views2/1804690/page4/bg4.png)
29
HPP › High pressure pumps
80
[
3.15
]
Ø132.5
[
5.22
]
Ø101
[
3.98
]
Ø138
[
5.43
]
Ø132.5
[
5.22
]
70
[
2.76
]
32
[
1.26
]
M12
M10
Ø35
+0.018
+0.002
1.37866
1.37803
Ø150
-0.014
-0.054
5.90496
5.90339
BELL HOUSING FOR HyDRAULIC MOTOR › KIT CAMPANA PARA ACOPLAMIENTO A MOTORES HIDRÁULICOS
› GLOCKEN-SET FÜR KOPPLUNG MIT HYDRAULIKMOTOREN › KIT CAMPANA PER ACCOPPIAMENTO A MOTORI
IDRAULICI › KIT CLOCHE POUR ACCOUPLEMENT à DES MOTEURS HYDRAULIQUES
EL
EL
FLANGE FOR DIRECT DRIVE MOUNT (OPTION) › BRIDA SOPORTE PARA ACCIONAMIENTOS DIRECTOS (OPCIONAL) ›
TRÄGERFLANSCH FÜR DIREKTE ANTRIEBE (SONDERZUBEHÖR) › FLANGIA SUPPORTO PER AZIONAMENTI DIRETTI (OP-
ZIONALE) › BRIDE DE SUPPORt POUR ACtIONNEMENtS DIRECtS (OPtION)
80
[
3.15
]
Ø114.5
[
4.51
]
Ø114.5
[
4.51
]
70
[
2.76
]
32
[
1.26
]
M12
Ø15
Ø35
+0.018
+0.002
1.37866
1.37803
[
5
]
Ø127
[
0.59
]
310.5
[
12.22
]
Kit Code:
5011 0295
BELL / CAMPANA / GLOCKE / CAMPANA / CLOCHE
Kit Code:
ON REQUEST
COUPLING / jUNTA / KOPPLUNG / GIUNTO / jOINT
Kit Code:
5011 0275
FLANGE / BRIDA / FLANSCH / FLANGIA / BRIDE
