General-Fujitsu AOHS18LDC [17/19] Outdoor unit

When you order parts, please make a photocopy of this page

and fill the number of the parts in the "Order" column.

OUTDOOR UNIT

1 Top Panel Assy 9309230057

2 Top Panel Seal 9309228016

3 Cabinet Assy 9314809040

4 Blow Down Grille 9308884015

5 Cabinet Right Assy 9309236011

6 Fan Ring 9308885012

7 Grip 9308880017

8 Switch Cover 9308882028

9 Protective Net 9315319012

10 4-Way Valve Assy 9315726018

11 Expansion Valve Assy 9311641018

13 Condenser 9311381037

14 Thermistor Spring-A 313728262708

15 Thermistor Spring 9300089012

16 Propeller Fan 9309909014

17 Nut 9304902003

18 Motor Bracket 9308872012

19 Separator Assy 9312971015

20 Base Assy, Painted 9308869081

21 3-Way Valve Assy 9315159014

22 2-Way Valve Assy 9313064013

24 Cord Clamp 9307271014

25 Terminal 9306489038

26 Inverter PCB Assy 9707039153

29 Fuse 0600382018

32 Expansion Valve Coil 9900057039

34 Fan Motor 9601725015

35 Compressor Assy 9313764012

36 Emblem 9315211019

Outdoor Temp. Thermistor

39 Solenoid Coil 9970033018

--- IPM 9705720015

--- 9900210045

Thermistor Assy--- 9900148027

Ref.

No.

Description

Part No.

AOHS18LDC

Ord.

Q'ty

2006.06.26 16
