General-Fujitsu AOHS18LDC [18/19] Standard accessories
![General-Fujitsu AOHS18LDC [18/19] Standard accessories](/views2/1804753/page18/bg12.png)
9305642045
Remote control
unit holder
Name and Shape Part No.
9310001004
9315027047
0600185527
0700076046
9310519004
9312153015
9311925033
Remote control unit
Battery (penlight)
Cloth tape
Tapping screw (big)
Wall hook bracket
STANDARD
ACCESSORIES
9306602017
Tapping screw (small)
( 3 x 12)
( 4 x 25)
0700019036
Air cleaning filter
Air cleaning filter
frame
INVERTER
2006.06.13 17
