General-Fujitsu ASG24UBBJ [35/40] 3 9 35
![General-Fujitsu ASG24FBBJ [35/40] 3 9 35](/views2/1804886/page35/bg23.png)
34 Capacitor (Fan Motor) 9704305060
40 Water Seal Plate 9369684005
45 Bracket (Evaporator) 9369372001
61 Decoration Plate-G 9368756017
63 Front Panel (ASY) 9368540012
69 Louver 9368560010
69-1 Louver Base-A 9368558017
69-2 Louver Base-B 9368559014
74 Air Filter 9368552008
92 Link Holder 9368563004
108 Base Assy 9369209017
122 Bearing Assy 9368574000
127 Drain Hose 9367695003
146-1 Evaporator-A Assy 9371347011
146-2 Evaporator-B Assy 9371348018
158 Joint Pipe Assy 9371341019
160 Front Drain Pan 9368546007
160-1 Rear Drain Pan 9368547004
163-2 Thermistor Spring-A 313728262708
164 Fan Motor Assy-IN 9601388012
169 Cross Flow Fan Assy 9368586003
178-1 Rubber (Motor) 9368575007
199 Step Motor 9900020019
233 Power Transformer 9900069018
236 Controller PCB Assy 9703335099
240 Remote Control Unit 9374322015
321 Flap 9368544010
329 Coupling Pipe Assy 9371333014
338-1 Motor Holder-B 9368551001
338-2
Motor Holder-C
9368769000
385 Indicator PCB Assy 9702307011
401 Wall Hook Bracket 9368579005
408 Louver Link 9368562007
425
Earth Plate
9368580001
428
Screw Cover
9368576011
435 Louver Spring 9368613006
473
Pipe Holder
9368565008
473-1 Cord Holder 9368566005
2005.03.09 35
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
506 Louver Rod 9368561017
514 Control Box 9368543006
522-1
Sector Gear
9368556006
522-2 Pinion Gear 9368557003
522-3 Flap Spring 9368612009
557 Diffuser Spring 9368587000
564
Bypass Pipe-A Assy
9369551000
574-1 Evaporator Support-R 9368549008
574-2
Evaporator Support-L
9368548001
588 Evaporator Holder 9368775001
684 Motor Base 9368555009
707 Display Cover 9368564001
735 Distributor 9371325019
743
Remote Control Unit Holder Case
9305642014
759 Intake Grill-G 9368542016
764 Drain Cap 9367677009
815 Terminal 9900016029
855 Cover Display 9369264016
855-1 Cover Display-B 9369594014
855-2 Cover Display-C 9369683015
938 Control Box Cover-R 9368570002
942 Control Box Cover 9368611002
960 Diffuser Assy 9369346019
963 Fan Guard 9368588007
963-1 Fan Guard Holder 9368554002
--- Room Thermistor 9703299179
--- Pipe Thermistor 9703297076
INDOOR UNIT
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASG30UBBJ
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASG30UBBJ
338 Motor Holder-A 9368550004
