45-4 Motor Bracket-B 9369628009
45-5 Motor Bracket-C 9369629006
45-6 Motor Bracket-D 9369630002
81 Strap 9362371001
46 Compressor Assy 9372558034
51 M5 Nut special 9300301015
55 Special Nut M8 9355091008
64 Cabinet Left, Painted 9359840022
2 Fan Cover (Guard) 9371187013
4 Emblem-Rear 313791088308
5 Cabinet-A, Painted 9359797029
9 Cabinet-B, Painted 9359798026
12 Base Assy, Painted 9359813019
13 3-Way Valve (5/8) 9372205037
13-2 3-Way Valve (3/8) 9372204047
16 Condenser Assy 9369981005
26 Comp. Cover 9369093005
29 Separate Wall 9359804017
32 Control Box Metal 9359839019
34 Capacitor (Fan Motor) 9357965024
37 Running Capacitor 9703107092
38 Capacitor Clamp 9351770013
39 Propeller Fan Assy 9359837015
41
Fan Motor Assy-Out (MFB-30DFT)
9600832011
45-3 Motor Bracket-A 9369627002
823-2 Fuse Holder 0500063024
824-4 Fuse 0600222529
867 Accumulator Holder Rubber 9354022010
989-1 Cord Clamp-A 9359822011
989-2 Cord Clamp-B 9359823018
272 Strainer 9369287008
328 Comp Plate Assy 9362273060
343 Solenoid 9900196011
342 Screw (Solenoid Valve) 9970024016
373 Grip 9352157004
344 4-Way Valve 9900163013
407 Clamp (Cable) No. 1259 313739340109
412 Terminal Gasket 9371512013
420 Capillary Assy 9371287102
477 Bell-Mouth 9359809012
527 Protection Net 9359844013
772 Joint Pipe (Valve) 9372876015
754 Gasket Washer 9351053017
815-3 Terminal-8P 9358660119
734 Cabinet Top Panel 9359799023
735 Distributor Assy 9369076008
2005.03.09 39
OUTDOOR UNIT
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOG30UNBDL
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOG30UNBDL
117-3 Hex. Nut w/Sp. Washer 301721180114
187 Clamp No. 1219 313361271706
218-3 Power Relay 9900074012
263 Accumulator 9385005006
82-1 Check Joint 9372802014
84 Valve Cover 9359817017
85 Valve Fixing Plate 9359806011
109 Terminal Cover 9371511016
107 Rubber Mount 9351049010
