5
Comfort born by fusion of
mounting of high-power DC motor
and new form
Know-how that realizing
high-power air flow
Wide rotating region from DC motor
low speed to high speed
New form optimizes air flow control
Powerful vertical air flow
Ideal air flow
New comfortable air flow comes from above in the cooling mode and
from below in the heating mode.
Healthy horizontal air flow
3
2
1
0 (m)
1
2
3
4
5
66
3
2
1
0 (m)
5
4
3
2
1
0 (m)
1
2
3
4
5
6
6
3
2
1
0 (m)
5
4
Every part of even a large room is comfortable.
Cool air reaches every part of even a large room.
Comfortable because it is warm at the
feet.
Comfortable because the occupants are
not directly exposed to the air flow.
It is warm, even at a distance.
Healthy because air does not cool the feet.
Comfortable because the occupants are
not directly exposed to the air flow.
Cool air reaches a long distance.
Double Big flaps
Movable power
diffuser (opened)
“Powerful straight down air flow” provides
powerful heating at foot level.
Movable power
diffuser (closed)
Indoor unit (Cross-section)
Indoor unit (Cross-section)
Heating area 1.5 times larger than existing Fujitsu General models
Cooling area
1.5 times larger than existing Fujitsu General models
Opening area is wide
Air blast upward
Cold air is discharged upward by the
Coander effect (discharge along a
surface) and it is delivered far away
along the ceiling
New arrangement heat exchanger
and large diameter long fan
placement by optimum balance
High Power DC Motor
Fan speed
High
900 1,000 1,100 1,200 1,300 1,400
(rpm)
Color-coding the operation state lets you check the
unit's operation status at a glance.
Large center display
Low operation (Low noise)
Cool/Dry/Fan
Heat
Washable
front panel
One-touch long-life filter
One-touch long-life filter
Removable,
washable drain pan
Easy maintenance
When the operation mode is set to Low when
sleeping, since the unit operates at a quiet
34dB ~ 39dB, you sleep soundly.
• 30dB is a level similar to a "whisper" in a quiet
room.
• 40dB is a sound level similar to the quietness
in a library.
For cleaning filter, wash once in 4 weeks, wipe
off the moisture, and remount to the body.
CEILING WALL TYPE
AWG18UA
5.40kW / 18,400BTU/h
5.70kW / 19,500BTU/h
AWG24UA
6.80kW / 23,200BTU/h
7.40kW / 24,600BTU/h
AWG18UB
5.40kW / 18,400BTU/h
5.70kW / 19,500BTU/h
AWG24UB
6.80kW / 23,200BTU/h
7.40kW / 25,300BTU/h
4.60kW / 15,700BTU/h
4.20kW / 14,300BTU/h
AWG14UB
AWH24L
6.80kW / 23,200BTU/h
7.00kW / 23,900BTU/h
AWH30L
8.00kW / 27,300BTU/h
8.50kW / 29,000BTU/h
For AWG30UB
For AWG18UA
18UB/24UB
For AWG14UB
For AWG24UA
AWH24L/30L
AWG30UB
7.90kW / 27,000BTU/h
8.40kW / 28,700BTU/h
