– 1 –
SPECIFICATIONS AND DIMENSIONS
TYPE COOL & HEAT INVERTER
INDOOR UNIT
ASY13PSACW
OUTDOOR UNIT
AOY13PNAC
COOLING CAPACITY ( ) : Range (kW) 3.7 (1.03 - 4.0)
HEATING CAPACITY ( ) : Range (kW) 4.85 (0.8 - 6.1)
POWER SOURCE (V) 220 - 230
FREQUENCY (Hz) 50
RUNNING CURRENT (A)
COOLING 6.8 - 6.5 <Max. 8.0>
HEATING 7.4 - 7.1 <Max. 10.0>
INPUT WATTS COOLING 1.48 (0.35 - 1.82)
( ) : Range (kW) HEATING 1.61 (0.33 - 2.28)
E.E.R. (kW/kW)
COOLING 2.50
HEATING 3.01
MOISTURE REMOVAL (R/hr) 1.8
AIR CIRCULATION-Hi
(m
3
/hr)
COOLING 610
HEATING 560
ELECTRICAL DATA
COMPRESSOR
DIMENSIONS
TYPE
Rotary type, Inverter, 2 pole,
Three phase, Induction motor
CODE 2PV132N7BB02
REFRIGERANT R-22 (g) 950
POWER SOURCE (V) 220 - 230
HI-SPEED COOLING 1,320
(r.p.m.) HEATING 1,420
INDOOR UNIT
MED-SPEED
COOLING 1,210
(r.p.m.) HEATING 1,260
LO-SPEED
COOLING 1,100
(r.p.m.) HEATING 1, 1,150
OUTDOOR UNIT (r.p.m.) 740 - 770
INDOOR UNIT
H x W x D (mm)
280 x 815 x 179
OUTDOOR UNIT 535 x 695 x 250
FAN MOTOR
WEIGHT
INDOOR UNIT
GROSS/NET (kg)
11 / 9
OUTDOOR UNIT 38 / 35
[ SPECIFICATIONS ]
Models : ASY13PSACW / AOY13PNAC
