General-Fujitsu AOY13PNCC [3/28] Models asy13psacw aoy13pnac

– 2 –

COOLING HEATING

HI-SPEED (dB) 43 42

INDOOR UNIT

MED-SPEED (dB) 40 39

LO-SPEED (dB) 38 36

SUPER QUIET (dB) 34 30

OUTDOOR UNIT (dB) 48 49

NOISE LEVEL

Between 5 m and 10 m, when using a connection pipe other than that in the table, charge additional refrigerant with 16 g / 1 m as the criteria.

ADDITIONAL REFRIGERANT CHARGE

Refrigerant suitable for a piping length of 5 m is charged in the outdoor unit at the factory.

When the piping is longer than 5 m, additional charging is necessary.

For the additional amount, see the table below.

PIPE LENGTH 5 m 7 m 10 m

ADDITIONAL REFRIGERANT None 32 g 80 g

The maximum length of the piping is 10 m. If the units are further apart than this,

correct operation can not be guaranteed.

Table

Models : ASY13PSACW / AOY13PNAC
