General-Fujitsu AOH14LMAKL [3/19] Outline and dimensions
![General-Fujitsu AOH14LMAKL [3/19] Outline and dimensions](/views2/1805582/page3/bg3.png)
235
66
250
440
580
( 650) (Grille measurement)
650
(Hanging bolt position)
400
(Hanging bolt position)
606
580 66
440
600
(Ceiling opening measurement)
250
60
86
Drain pipe (I.D. 32)
54
46
131
111
47
(unit : mm)
INDOOR UNIT
OUTLINE AND DIMENSIONS
650
650
Models :
AUH12LBAB
AUH14LBAB
20
35
2006.04.27 2
