ECS Elitegroup H310CH5-M11 [6/73] Chapter 1 introducing the motherboard

H310CH5-M11

USER MANUAL

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the H310CH5-M11 motherboard. This motherboard is a high

performance, enhanced function motherboard designed to support the LGA1151

socket for

Intel

Coffee Lake processor.

This motherboard is based on Intel

H310 Express Chipset for best desktop platform

solution. It supports up to 32 GB

of system memory with dual channel DDR4 2666/

2400 MHz. One PCI Express x16 Gen3 slot is supported, intended for Graphics Inter-

face. In addition, one PCI Express x1 Gen2 slot is for extending usage.

It integrates USB 2.0 and USB 3.1 interface, supporting up to six USB 2.0 ports (two

USB 2.0 ports at rear panel and two USB 2.0 header supports additional four USB 2.0

ports) and four USB 3.1 ports (two USB 3.1 ports at the rear panel and one USB 3.1

header supports additional two USB 3.1 ports).

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one PS/2 mouse & keyboard connector, one HDMI port, one VGA port, two

USB 3.1 ports, two USB 2.0 ports, one RJ45 LAN connector, and audio jacks for line-in,

line-out and microphone.

In addition, this motherboard supports four SATA 6Gb/s connectors for expansion.

Your motherboard package ships with the following items:

Package Contents

H310CH5-M11 Motherboard

User Manual

DVD

I/O Shield

2 SATA 6G Cables



The package contents above are for reference only, please take the actual package items as

standard.
