Chapter 1
2
H310CH5-M11
USER MANUAL
Brief Introduction
Specifications
CPU
• Intel
®
H310 ChipsetChipset
• Supported by Intel
®
H310 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Storage
• LGA1151 socket for
Intel
®
Coffee Lake processor
• Supports CPU up to 65W
• 1 x PS/2 mouse & keyboard connector
• 1 x HDMI port
• 1 x VGA port
• 2 x USB 2.0 ports
• 2 x USB 3.1 Gen1 ports
• 1 x RJ45 LAN connector
• 1 x Audio 6-ch jacks (line-in, line-out, microphone)
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit Lan
• Realtek ALC662-VDD-GR 6-CH High Definition audio CODEC
- Compliant with HD audio specification
Audio
Internal I/O
Connectors &
Headers
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 3.1 Gen1 header (2 ports)
• 2 x USB 2.0 header (4 ports)
• 4 x SATA 6Gb/s connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x COM header
• 1 x Buzzer header
• 1 x Case open header
• 1 x Clear CMOS jumper
Expansion
Slots
• 1 x PCI Express x16 Gen3 slot
• 1 x PCI Express x1 Gen2 slot
• Dual-channel DDR4 memory architecture
• 2 x 288-pin DDR4 LONG DIMM sockets support up to 32 GB
• Support DDR4 2666/2400 MHz SDRAM
Memory
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
