Haier HSU-07LE03 [19/78] Domestic air conditioner
![Haier HSU-07LE03 [19/78] Domestic air conditioner](/views2/1806485/page19/bg13.png)
16
Domestic Air Conditioner
7 59.4984 55.9729 52.5917 -1.20 1.15
8 56.3905 53.1320 50.0006 -1.17 1.13
9 53.4631 50.4521 47.5523 -1.15 1.11
10 50.7048 47.9230 45.2384 -1.13 1.09
11 48.1049 45.5355 43.0505 -1.10 1.07
12 45.6534 43.2808 40.9813 -1.08 1.04
13 43.3410 41.1509 39.0236 -1.05 1.02
14 41.1592 39.1381 37.1708 -1.03 1.00
15 39.0998 37.2355 35.4167 -1.00 0.98
16 37.1553 35.4363 33.7555 -0.98 0.96
17 35.3186 33.7344 32.1818 -0.95 0.94
18 33.5833 32.1240 30.6905 -0.93 0.91
19 31.9432 30.5997 29.2769 -0.90 0.89
20 30.3925 29.1565 27.9365 -0.88 0.87
21 28.9259 27.7895 26.6651 -0.85 0.84
22 27.5383 26.4944 25.4589 -0.83 0.82
23 26.2252 25.2670 24.3140 -0.80 0.80
24 24.9822 24.1034 23.2271 -0.78 0.77
25 23.8050 23.0000 22.1950 -0.78 0.77
26 22.7500 21.9499 21.1520 -0.78 0.78
27 21.7477 20.9536 20.1638 -0.82 0.81
28 20.7951 20.0081 19.2272 -0.86 0.85
29 19.8895 19.1104 18.3394 -0.89 0.88
30 19.0285 18.2581 17.4974 -0.93 0.92
31 18.2094 17.4484 16.6988 -0.97 0.95
32 17.4302 16.6792 15.9410 -1.00 0.99
33 16.6885 15.9480 15.2217 -1.04 1.02
34 15.9825 15.2530 14.5389 -1.08 1.06
35 15.3103 14.5920 13.8903 -1.12 1.09
36 14.6700 13.9632 13.2743 -1.16 1.13
37 14.0599 13.3650 12.6889 -1.20 1.16
38 13.4786 12.7957 12.1325 -1.23 1.20
39 12.9244 12.2537 11.6035 -1.27 1.24
40 12.3960 11.7375 11.1004 -1.31 1.27
41 11.8921 11.2459 10.6218 -1.35 1.31
42 11.4113 10.7775 10.1665 -1.39 1.34
43 10.9526 10.3311 9.7330 -1.43 1.38
44 10.5147 9.9056 9.3204 -1.48 1.42
45 10.0967 9.4999 8.9275 -1.52 1.45
46 9.6976 9.1130 8.5532 -1.56 1.49
47 9.3163 8.7439 8.1965 -1.60 1.53
48 8.9521 8.3916 7.8566 -1.64 1.57
49 8.6040 8.0554 7.5327 -1.68 1.60
50 8.2713 7.7345 7.2237 -1.73 1.64
51 7.9531 7.4280 6.9291 -1.77 1.68
52 7.6489 7.1353 6.6480 -1.81 1.72
+6807,LE03 )XQFWLRQV DQG &RQWURO
