Operation
HEALTH Operation
2.Health anion function
Press the ON/OFF switch
1.Unit start
Press the " HEALTH"again, then the healthy function
stops.
The anion generator in the air conditioner can generate a lot of anion
effectively balance the quantity of position and anion in the air and also to
kill bacteria and speed up the dust sediment in the room and finally clean
the air in the room.
Brief introduction to health anion function
3.To Cancel HEALTH Model
is displayed on the remote
HEALTH ON/OFF
FAN
MODE
SWING
TIMER
CLOCK
SET
SLEEP
LOCK
RESET
Press HEALTH button
controller and is displayed on the display
board .
When indoor fan motor is running, it has healthy
process function. (It's available under any mode)
NOTE: If the unit which you purchased has healthy function,follow it.If not,please ignore.
