Chapter 3
BSWI-D USER MANUAL
34
CPU Configuration
The item in the menu shows the CPU information.
Scroll to this item and press <Enter> to view the following screen:
Socket 0 CPU Information
Intel(R) Pentium(R) CPU J3710 @ 1.60GHZ
This is display-only field and displays the information of the CPU installed in your
computer.
CPU Signature (406C4)
This item shows the information of the CPU signature.
Microcode Patch (408)
This item shows the version of Microcode patch.
Max CPU Speed (1600 MHz)
This item shows the max speed of the CPU.
Min CPU Speed (480 MHz)
This item shows the min speed of the CPU.
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset M.I.B X Boot Security Exit
CPU Configuration
Socket 0 CPU Information
CPU Speed 1600 MHz
64-bit Supported
Limit CPUID Maximum [Disabled]
Bi-directional PROCHOT [Enabled]
Intel Virtualization Technology [Enabled]
Power Technology [Energy Efficient]
Enhanced Halt (C1E) [Enabled]
Socket specific CPU Information
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset M.I.B X Boot Security Exit
Socket 0 CPU Information
Intel(R) Pentium(R)CPU J3710 @ 1.60GHz
CPU Signature 406C4
Microcode Patch 408
Max CPU Speed 1600 MHz
Min CPU Speed 480 MHz
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-X Technology Supported
L1 Data Cache 24 KB X 4
L1 Code Cache 32 KB X 4
L2 Cache 1024 KB X 2
L3 Cache Not Present
