Chapter 1
2
BSWI-D USER MANUAL
SoC
Specifications
• Signal channel DDR3L SO-DIMM memory architecture
• 1 x 204-pin DDR3L SO-DIMM socket supports up to 8 GB
• Supports DDR3L 1600 MHz DDR3 SDRAM
Memory
• 1 x mini PCI Express slot
(the mini PCIE (half-card) supports wireless card/Bluetooth
extension card)
• Supported by Intel
®
Braswell SoC
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit LAN
• Realtek ALC662 6-CH HD Audio CODEC
• Realtek ALC105 4ohm 3w Amplifier (optional)
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
• Onboard Intel
®
Braswell Pentium QC N3700/Celeron QC
N3150/Celeron DC N3050 or other SoC
• Supports TDP up to 6W
• 1 x 4-pin 19V power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x 2*5-pinUSB 2.0 header supports additional two USB 2.0
ports
• 1 x 1*5-pin USB 2.0 header supports additional one USB 2.0
port
• 2 x Serial ATA 6Gb/s connectors
• 1 x BZ
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x BKLT_PWR jumper (optional)
• 1 x LVDS select jumper (LCD_PWR) (optional)
• 1 x LVDS connector
• 1 x MONO jumper
• 1 x LVDS brightness control header (DISP_BRT) (optional)
• 1 x LPT header
• 2 x COM headers
Internal I/O
Connectors &
Headers
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x DC_IN port
• 1 x DC_Out port (optional)
• 1 x PS/2 Keyboard & PS/2 Mouse connectors
• 1 x D-sub (VGA) port
• 1 x HDMI port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x Audio port (1 x line-in, 1 x line-out, 1 x Microphone)
