BAT-I2 USER MANUAL
46
Chapter 3
This page enables you to set setup administrator and password.
Security Menu
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F1:General Help
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Set Administrator Password
Main Advanced Chipset M.I.B III Security Boot Exit
Administrator Password Status Not Installed
User Password Status Not Installed
Administrator Password
Secure Boot menu
Administrator Password Status (Not Installed)
This item shows administrator password installed or not.
User Password Status (Not Installed)
This item shows user password installed or not.
Secure Boot menu
Scroll to this item and press <Enter> to view the following screen.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Secure Boot can be enabled if
1. System running in User mode
with enrolled Platform Key(PK)
2. CSM function is disabled
System Mode Setup
Secure Boot Not Active
Secure Boot [Disabled]
System Mode (Setup)
This item shows system of secure boot (can be setup or user).
Main Advanced Chipset M.I.B III Security Boot Exit
Secure Boot (Not Active)
This item shows the active state of secure boot.
Secure Boot (Disabled)
Use this item to enable or disable secure boot state.
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
