Haier air conditioner Edition: 1.0-061028
- 5 -
2. Specification
Item
HSU-22LV03
Power PH, V, Hz 1, 220, 50
Climate Type T1
Starting Current A
Cooling Capacity W 6200
Rated Power W 2350
Rated Current A 11.3
Max Power W 2950
Max Current A 12.6
Cooling
EER W/W 2.64
Heating Capacity W /
Rated Power W /
Rated Current A /
Max Power W /
Max Current A /
Heating
EER W/W /
Cooling
℃
18~46 Operating temp.
range
Heating
℃
/
H rpm 1350
M rpm 1250
Indoor fan Velocity
L rpm 1150
Outdoor fan Velocity rpm 860
Indoor Air Volume (High) m
3
600
Max. pressure at warm side MPa 2.8
Moisture Removal 10
-3
m
3
/h 2.4
Indoor (H/M/L) dB(A) 43/39/35
Noise Level
Outdoor dB(A) 56
Net Kg 12
Indoor Weight
Gross Kg 15
Net Kg 45
Outdoor Weight
Gross Kg 50
Net mm 870*305*225
Indoor Dimension
Package mm 962*312*365
Net mm 780*250*650
Outdoor Dimension
Package mm 908*342*712
Manufacture RECHI
Type 55R613GW-8ASM
Compressor
Oil Charge CC 710
Type R22
Net Charge g 1400
Refrigerant
Charge if over standard pipe
length
g/m 16
Unit
Model
