HSU-18,22C03/V(ZXF) Functions and Control
16
54 7.0796 6.5884 6.1237 -1.90 1.79
55 6.8131 6.3329 5.8793 -1.94 1.83
56 6.5581 6.0887 5.6459 -1.99 1.87
57 6.3140 5.8552 5.4230 -2.03 1.91
58 6.0802 5.6318 5.2100 -2.07 1.95
59 5.8563 5.4181 5.0065 -2.12 1.99
60 5.6417 5.2136 4.8120 -2.16 2.03
61 5.4361 5.0178 4.6260 -2.21 2.07
62 5.2391 4.8304 4.4481 -2.25 2.11
63 5.0502 4.6510 4.2780 -2.30 2.15
64 4.8691 4.4791 4.1153 -2.35 2.19
65 4.6954 4.3145 3.9596 -2.39 2.23
66 4.5287 4.1567 3.8105 -2.44 2.27
67 4.3689 4.0055 3.6678 -2.49 2.31
68 4.2154 3.8605 3.5312 -2.53 2.35
69 4.0682 3.7216 3.4004 -2.58 2.39
70 3.9268 3.5883 3.2750 -2.63 2.43
71 3.7910 3.4605 3.1549 -2.68 2.48
72 3.6606 3.3378 3.0398 -2.73 2.52
73 3.5353 3.2201 2.9294 -2.77 2.56
74 3.4150 3.1072 2.8237 -2.82 2.60
75 3.2993 2.9987 2.7222 -2.87 2.64
76 3.1881 2.8946 2.6249 -2.92 2.68
77 3.0812 2.7946 2.5316 -2.97 2.73
78 2.9785 2.6986 2.4420 -3.02 2.77
79 2.8796 2.6063 2.3560 -3.07 2.81
80 2.7845 2.5176 2.2735 -3.12 2.86
81 2.6931 2.4324 2.1943 -3.17 2.90
82 2.6050 2.3505 2.1182 -3.22 2.94
83 2.5203 2.2717 2.0451 -3.28 2.99
84 2.4388 2.1960 1.9749 -3.33 3.03
85 2.3602 2.1231 1.9075 -3.38 3.07
86 2.2846 2.0530 1.8426 -3.43 3.12
87 2.2118 1.9856 1.7803 -3.48 3.16
88 2.1416 1.9207 1.7204 -3.54 3.20
89 2.0740 1.8582 1.6628 -3.59 3.25
90 2.0089 1.7981 1.6074 -3.64 3.29
91 1.9461 1.7402 1.5541 -3.70 3.34
92 1.8856 1.6844 1.5028 -3.75 3.38
93 1.8272 1.6307 1.4535 -3.80 3.43
94 1.7709 1.5789 1.4060 -3.86 3.47
95 1.7166 1.5291 1.3603 -3.91 3.52
96 1.6643 1.4810 1.3163 -3.97 3.56
97 1.6138 1.4347 1.2739 -4.02 3.61
Domestic Air Conditioner
