Haier AP602AKEAA [17/30] Maintenance
![Haier AP602AKEAA [17/30] Maintenance](/views2/1808422/page17/bg11.png)
15
Don't spray any paint or insecticide
on the unit.
Don't splash water directly on indoor
unit.
This will cause damage or even fire accident.
This could be
very dangerous
Maintenance
Disconnect power supply Don't touch it with wet
hand
Don't wash with hot water
or solvent to clean the unit
Pull it out from top as shown in Fig.
Use water or vacuum cleaner to clean it.
If it is extremely dirty, wash it with neutral
detergent or soap water.
Wash it with clean water and install it after
complete dry.
Air filter cleaning
Don't use hot water over 40 C, as this may cause damage to air filter.
Wipe air filter carefully.
Caution:
