Haier AD182XLERA [12/28] Customer need to know
![Haier AD182XLERA [12/28] Customer need to know](/views2/1808649/page12/bgc.png)
10
Customer Need-to-know
Customer Need-to-know
Please install the air conditioner according to the requirements specified in this manual to ensure
the air conditioner work well.
Be careful not to scratch the surface of the case during moving the air conditioner.
Please keep the installation manual for future reference when maintenance and changing
installation place.
After installation ,please use the air conditioner according to the specification in the operation
manual.
Using Directions
Adjust suitable airflow direction Avoid direct sunlight and airflow
Keep the proper indoor temperature.
Too cool or hot is not good for your health.
Furthermore,it will result in excessive
consumption of electric power.
After finishing installation, please confirm there is no refrigerant leakage.
Best
temperature
Effectively use timer.
Using TIMER mode, you can make the room
temperature reach a suitable temperature
when you wake up or go back home.
ATTENTION!
