Haier AD182XLERA [15/28] Instructions to installation

PRECAUTION

Execute proper grounding. Do not connect the earth wire to a gas pipe, water pipe, lightening

rod, or a telephone ground wire. Improper placement of earth wires can result in electric shock.

An electric leakage breaker must be installed, otherwise electric shock or other accidents would

occur.

After completion of the installation, the air conditioner shall be electrified to check for electric

leakage.

2. Preparation for installation

Installation tools

7 Pipe Cutter

14 Refrigeration Oil

6 Spanner

13 Scraper or File

5 Shifting Spanner

12 Measuring Tape

4 Inner Hexagon Spanner

11 Leakage Checker or Soap Liquid

3 60mm Drill

10 Clippers

2 Steel Saw

9 Knives

1 Screw Driver (flat head, wabbler, triangle)

8 Pipe Expander

Instructions to installation

WARNING

Its improper installation can also result in heat generation or fire.

When setting up or moving the location of the air conditioner, do not mix air etc. or anything

other than the designated refrigerant within the refrigeration cycle.

Rupture and injury caused by abnormal high pressure can result from such mixing.

Always use accessory parts and authorized parts for installation construction. Using parts

not authorized by this company can result in water leakage, electric shock, fire and refrigerant

leakage.

CAUTION

Execute proper grounding. Do not connect the ground wire to a gas pipe, water pipe, lightning

rod or a telephone ground wire. Improper placement of ground wires can result in electric

shock.

The installation of an earth leakage breaker is necessary depending on the established

location of the unit. Not installing an earth leakage breaker may result in electric shock.

Do not install the unit where there is a concern about leakage of combustible gas.

The rare event of leaked gas collecting around the unit could result in an outbreak of fire.

For the drain pipe, follow the installation manual to insure that it allows proper drainage and

thermally insulate it to prevent condensation. Inadequate plumbing can result in water leakage

and water damage to interior items.
