4
THE NAME OF EACH PART AND ITS FUNCTION
Indoor unit
Unit indication section
(Power, Timer, Run, Pump)
Remote controller signal receiver
The signal is received.
Back up switch
Swing louver
Air blows out from here.
Air flow direction is adjusted.
Wireless Remote controller
Air inlet grille
T akes in the indoor air .
Air filter
Removes dust or dirt out of the inlet air .
(In the Air inlet grille)
Air inlet
Outdoor unit
Air outlet
Compressor(inside of unit)
