Haier HSU-12H03/R(DB) [24/27] Maintenance

Note:the green aspect of the bacteria-killing

medium air purifying filter will face outside, the

white aspect will face to the machine. The

yellow aspect of the VC layer will face outside,

the white aspect will face to the machine.

The inlet grill is supported by its top

plate at the right side.

3.Take the VC layer + Bacteria-killing

medium sets

Put down the inlet grill’s top plate, and close the inlet grill.

(AIP board)

(

Handle

)

In order to keep the AIP layer having a highly work effect ,it should be cleaned regularly or

aperiodically just according to the working environment.

1. Turn off the A/C electricity supply and make sure that AIP layer is not working.Then clean the

AIP layer after turning off it five minutes later.

2. Please brush off the dust on AIP board,then steep it into cleaning agent water and wash it.

3. After cleaning AIP board pleas put it on a dry place until it is totally dry.

4. Ensure AIP board is dry enough then install it in the its position along the slide way .

In the use, please note to clean the filter frequently (take off the back suction cleaner or lightly pat it)

to avoid the operating effect is lowered due to the dust covering the filter. AIP layer and bacteria-killing

medium filter is strictly prohibited from being cleaned by water.
