Maintenance :spray gun

- After use, the paint spray gun must be cleaned thoroughly.

- After disposing of any material not used, add a small quantity of paint thinner to paint cup A and use

the spray paint gun again as during spraying, fully pressing trigger G and complying with the same

safety precautions. This operation permits initial cleaning of the fluid ducts.

-To clean, unscrew nozzle D and ring E ( . ).

- Disassemble the spraying needle by unscrewing knob H and extracting spring L and needle M ( .

- Lubricate the socket of the spraying needle N at regular intervals ( . ).

- Thoroughly clean these items with a suitable product.

-Also clean the fluid passage through the socket of paint cup A ( . ).

fig 5

fig

fig 6

fig 1

5. Air blow gun

1. Connect the air blow gun to the compressor as explained in chapter 3.

2.Adjust working pressure to the value indicated for this accessory.

3. To use the air blow gun, press lever D and direct the nozzle B towards the surface to be cleaned

(-).

,,,, .

figures 1 2

Clean the carpets of your home or car mats very efficiently using the blow gun It is also ideal for

keyboards electrical items refrigerators cameras TV cameras glassware and vacuum cleaners
