Технические данные Страница: 20

Haier HSU-12RG03 [20/54] Domestic air conditioner

Domestic Air Conditioner

No. in

exploded

view

Spare parts number

Spare parts description in

english

Model QTY. Failure rate

The proportion

of the spare

part stock

remark

1 0010100777 Front grille HSU-12H03/VA(ZXF) 1

2 0010100775 Front panel HSU-12H03/VA(ZXF) 1

3 0010200212 Fan HSU-12H03/VA(ZXF) 1

4 0010402289 Motor HSU-12H03/VA(ZXF) 1 *

5 0010802042 Frame for motor HSU-12H03/VA(ZXF) 1

6 0010149003 Heat exchanger left plank HSU-12H03/VA(ZXF) 1

7 0010705188 Heat exchanger HSU-12H03/VA(ZXF) 1

8 0010100774 Top panel HSU-12H03/VA(ZXF) 1

9 0010100779 Electric box HSU-12H03/VA(ZXF) 1

10 0010100776 Right panel HSU-12H03/VA(ZXF) 1

11 001A3600007A Fan Motor Capacitor HSU-12H03/VA(ZXF) 1 *

12 001A3600021 Compressor Capacitor HSU-12H03/VA(ZXF) 1 *

13 0010402287 Terminal block HSU-12H03/VA(ZXF) 1 *

14 0010101027 Heat exchanger right plank HSU-12H03/VA(ZXF) 1

15 ……………… Tube assy HSU-12H03/VA(ZXF) 1

16 001A2500004 4-way valve winding HSU-12H03/VA(ZXF) 1

17 0010705268 Capillary Tube HSU-12H03/VA(ZXF) 1

18 0010703597 Stop valve HSU-12H03/VA(ZXF) 1

19 0010703596 Stop valve HSU-12H03/VA(ZXF) 1

20 0010703960 Compressor HSU-12H03/VA(ZXF) 1 *

21 0010100778 Bottom plate HSU-12H03/VA(ZXF) 1

22 0010100782 Separating plate HSU-12H03/VA(ZXF) 1

23 0010200491 Left handle HSU-12H03/VA(ZXF) 1

24 001A1436160 Right handle HSU-12H03/VA(ZXF) 1

25 0010203305 Service cover HSU-12H03/VA(ZXF) 1

26 0010202004 Sound insulating cushion HSU-12H03/VA(ZXF) 1

27 0010402288 Wires group HSU-12H03/VA(ZXF) 1

28 0010802091 Fresh air device HSU-12H03/VA(ZXF) 1

4,not need provided :The spare-part which is seldom damaged or the maintenance man could not maitmains.The spare parts may be air freighted by the

factory if they were damaged.The customer nees not stock in the spare-part warehouse,should be marked with " x ".

5,Above should be improved accord with the reply of the market half a year per time.

6.The spare parts price on net is FOB Qingdao term.

1,The failer rate and the proportion of the spare-part stock are regarded as the reference of the stock for spare-parts;The first time should be stocked

accroded with the proportion of the spare-parts,and it should be adjusted with the actual quantity 3 months later.

2,easy-damaged;The spare-part which is often damaged and the customer must stock in the spare-parts warehouse,and should be marked with"*"

3,possible damaged:The spare-part which is not often damaged like the easy damaged one and the customer may stock in the spare-part warehouse

accord with the actual case,should be marked with " ".

Model:HSU-12RG03

OUTDOOR UNIT

Haier HSU-12RG03 [20/54] Domestic air conditioner
