12. Remote control
. Start or stop running with the remote-control signals.
. Only OFF signal is accepted when there are emergencies or malfunctions.
1 second delay: Starting, stopping and signals except the wind direction signal all begins 1
second after the receiption of the signal.
13.EEPROM control
. EEPROM is wrong when the EEPROM parameter sum does not accord with the check
sum after the outdoor unit is powered on.
. The outdoor unit EEPROM is wrong will be displayed when the indoor unit receives
wrong EEPROM signals from the outdoor unit.
. In this case the control and emergency operation are not allowed.
. Power-off to disarm.
14 .Trouble Records
. There are no lists if there are no error code records.
. The malfunction display will automatically disappear after 10 seconds.
The remote control accepts stop signal only. The malfunction record may end according to
the ON/OFF or remote-control’s stop signal
. Models with EEPROM can store the records when they are replugged to the power.
15. Special functions
1、The indoor unit operates only
a. To enter into this function please press the sleep key 6 times with 6 beeps in 7 seconds under the
none-power-failure-compensation mode.
b. ：The indoor unit operates as follows after entering into the function.
The indoor unit operates and communicates according to the setting without processing the signals
from the outdoor unit but needs to send signals to the outdoor unit without stop.
c. To exit this function please press the OFF key of the remote-controller or the emergency key to
power off the unit. You can also unplug the machine to exit this function.
When the indoor unit operates independently, it imitates the outdoor unit to send the following signals
to the indoor unit.
Output frequency 58 Hz ,error frost removing state: 17654=0001,13=0,121=01 ,external temperature
level K54=00, the indoor heat-exchange temperature is fixed at 47℃
16. Malfunction explanation
Error symbals
Anomaly
PowerTiming Running
Indo
or
O
ut
do
or
Autom
atic
restore
Causes
Indoor thermister
anomaly
★ ■ ■
* *
1．
Poor connection of the connectors or
bad control base plate
Heat-exchange
thermister
anomaly
★ □ □
* *
1．Poor connection of the connectors
or bad control base plate
Frost-removing
thermister
anomaly
□ □ ★
**
1．Poor connection of the connectors
or bad control base plate
Output thermister
anomaly
★ □ ■
**
1．Poor connection of the connectors
or bad control base plate
Air Conditioner
