Please carefully read the installation instruction.
Illustrations of cabinet dimensions and installation positionof the dishwasher
Pr epar ation s s hould b e m ade befor e m oving t he dish wash er t o t he i nsta llation p lace.
Choose a place near the sink to facilitatethe installation of inlet and drain hoses
(see figure1).
If dishwasheris installed at the corner of the cabinet, thereshouldbe some space
(illustratedin figure 2) whenthe door isopened.
2
1
Minimum space when
the door i s ope ned
【】
Figure2
【】
Figure1
Cabinet dimensions
Less than5mm
between the top
of dishwasher and
cabinet and the
outerdoor aligned
to cab inet .
1 The aest he ti c wo oden p anel co uld be p ro cess ed acc or ding t o th e Fi gure 3.
Th e aest heti c pane l s hould
be pro ces sed in acc or dance
with theillustrated dimensions
【Figure
3】
(Un it: mm )
18
Cabinet
Di shw a sh er
Door of
dishw asher
Minimum space of 50m m
90 °
90°
450 mm
820mm
100
580mm
80
Space between c abinet
bottom and floor
Electrical, drain
and water supply
line entrances
5~12
10~17
The lengt h of the panel should be within
the r ange of 506~5 80mm.
442
179 175
38
418
