FEATURES AND BENEFITS
Top Panel
Top Panel
Bottom Panel
Side Panel (s)
10 step adjustments of ESP
ESP can be adjusted by the supplied wired
controller YR-E17 or the alternate controller
YR-E16. No need to open the electrical box and adjust
the ESP by switch or plug, reducing installation time.
Static pressure
Adjusted by controller
Serviceability
Top, bottom or side panels are removable for
servicing and installation (10.5 - 16 kW)
Service
Safety Drain Tray Built In
The 10.5 to 16 kW indoor unit is designed to
incorporate two drain trays for condensate
removal. The secondary tray is a backup in case the fi rst
one overfl ows due to a blockage.
20 & 24 kW 2 piece design.
The 20 & 24 kW indoor unit can be separated
into two manageable pieces to make installation
easier. Then can be reassembled back into one piece in
the ceiling.
20
0
200 400 600 800 1000
40
60
80
100
40%
35%
25%
20
0
200 400 600 800
1000
40
60
80
100
90%
87.5%
85%
Torque(kgfcm)
Rev(r/min)
AC motor efficiency DC motor efficiency
Rev(r/min)
Torque(kgfcm)
DC Fan Motor
DC motor's are renown for using less energy
than a standard AC motor and being more
adjustable for better airfl ow / static pressure tuning.
Design
The 10.5- 16kW indoor unit design was
optimised to ensure the compact indoor
unit was kept to a maximum of only 550mm. Ideal for
600mm truss spacing of a normal house.
490mm
- 11 -
