Installation drawings of indoor and outdoor units
Connection cautions
model
3U19FS2ERA
3U24GS2ERA
4U30HS2ERA 5U34HS2ERA
connection priority between indoor and
stop valve higher from down to up
when there is 1 indoor,the prior stop
valve is
when there are 2 indoors,the prior
stop valves are
when there are 3 indoors,the prior
stop valves are
when there are 4 indoors,the prior
stop valves are
when there are 5 indoors,the prior
stop valves are
Note: For better oil return and more reliable system, please execute as the above when connecting indoor unit.
C
C B
C B A
D
D C
D C B
D C B A
E
E D
E D C
E D C B
E D C B A
A
B
C
D
E
A
B
C
D
A
B
C
