Haier AU42NAIMCA [5/33] Indoor unit
![Haier AU42NAIMCA [5/33] Indoor unit](/views2/1814756/page5/bg5.png)
Parts
3
1
2
3
4
1
Outlet grill
2
Operation panel
3
Inlet grill
4
Air filter
5
Remote-controller
Indoor unit
AM
TEMP
SWING
FAN
ON
OFF
MODE SLEEP
SET
CLOCK
TIMER
RESET
5
LOCK
6
7
Outdoor unit
Air inlet
6
7
[At side and rear]
Air outlet
