Model AU48NFIERA (G) AU60NFIERA (G)
Power supply Ph/V/Hz 3/380~400/50/60 3/380~400/50/60
Cooling
Rated capacity kW 15 18
Rated capacity kBtu/h 51.2 61.4
Rated power input kW 4.2 5.5
Max. power input kW 6.2 7.3
EER 3.57 3.27
Rated current A 6.7 9.8
Max. current A 10 13
Heating
Rated capacity kW 17 20
Rated capacity kBtu/h 58 68.2
Rated power input kW 4 5.25
Max. power input kW 5.8 6.7
COP 4.25 3.81
Rated current A 6.4 9.4
Max. current A 9.6 12
Compressor
Brand MITSUBISHI ELECTRIC MITSUBISHI ELECTRIC
Model LNB42F LNB42F
Type Rotary Rotary
Compressor quantity 1 INV 1 INV
Capacity W 13980W 13980W
Power input W 4270W 4270W
Rated current (RLA) A 12 12
Speed rps 60 60
Crankcase heater W 28 28
Refrigerant oil brand IDEMITSUKOSAN CO.,LTD IDEMITSUKOSAN CO.,LTD
Refrigerant oil type FV50S FV50S
Refrigerant oil charge ml 1400 1400
Outdoor fan motor
Brand PANASONIC PANASONIC
Model EHDS80BAS EHDS80BAS
Voltage 208-230 208-230
IP class IP23 IP23
Type DC DC
Insulation class E E
Safe class I I
Power input W 124 124
Output W 100*2 100*2
Rated current A 0.4 0.4
Capacitor μF / /
Speed rpm 960 960
Outdoor fan
Brand SHUNWEI SHUNWEI
Model / /
Material Plastic Plastic
Type Axial Axial
Diameter mm 450 450
Height mm 148 148
